Optris – CSmicro LT HS Pyrometer

Code: CSmicro LT HS

CSmicro LT HS Pyrometer sets new performance standards in the measurement of slightest temperature differences of 0.025 K.

Share (0)
Total: 0 Total: 0 Total: 0 Total: 0

Description

CSmicro LT HS Pyrometer

The pyrometer optris CSmicro LT HS sets new performance standards in the measurement of slightest temperature differences of 0.025 K. Due to the stainless steel measuring head, it is perfectly suited for installation in especially limited and cramped spaces.

The compact infrared thermometer measures precisely in a temperature range from -20°C to 150°C and is equipped with an intelligent LED display, utilizable as alarm signalization, target support, self-diagnosis or temperature-code display.

Key Features & Benefits:

  • Temperature range: -20 to 150°C
  • Spectral range: 8 to 14 µm
  • Response time: 150 MS

SPECIFICATION
Measurement Specifications
  Temperature range   -20 … 150°C
  Spectral range   8 – 14 µm
  Optical resolution   15:1
  CF-lens (optional)   3.4 mm @ 50 mm
  System accuracy   ± 1.0% or ± 1.0°C1)2)
  Repeatability   ± 0.3% or ± 0.3°C1)2)
  Temperature coefficient   ± 0.05 K/K or ± 0.05 %/K3)
  NETD   0.025 K4)
  Response time (90%)   150 ms
  General Specifications
  Environmental rating   IP 65 (NEMA-4)
  Ambient temperature   -20 … 85 °C (sensing head)
  -20 … 80 °C (electronics)
  -20 … 75 °C (electronics / mA version)5)
  Storage temperature   -40 … 85°C
  Relative humidity   10 – 95%, non condensing
  Vibration   IEC 60068-2-6 / -64
  Shock   IEC 60068-2-27 (25 G and 50 G)
  Weight   200 g
  Electrical Specifications
  Output / analog   0 – 5/10 V (mV version) or 4 – 20 mA (mA version)
  Output / alarm   0 – 30 V / 50 mA (open collector)
  (mA version: 500 mA)
  Output/ digital   uni- / bidirectional, 9.6 kBaud, 0/3 V digital level / USB optional
  LED-functions   alarm indication, automatic aiming support, self diagnostic,
  temperature indication (via temperature code)
  Input (0 – 10 V)   Programmable functional input for external emissivity setting6)
  / ambient temperature adjustment6), triggered signal output or peak-hold function
  Cable length   head – electronics: 0.5 m (standard)
  after electronics: 0.5 m (standard), 3 m, 6 m
  Power supply   5-30 V DC
  Current draw   9 mA (mV version)



เอกสารข้อมูลผลิตภัณฑ์

Download File : Datasheet CSmicro LT HS
